Optical Fiber Cable (OFC) continues to be the backbone of the digital world. The exponential rise in the digital population and the consequent explosion in data consumption is necessitating the increase in speed and bandwidth of OFC networks. Our OFC products and capabilities have constantly been evolving, enabling us to sustain the market leadership in OFC manufacturing.
1F to 1152F, our cable solutions are customizable for varied applications and customer requirements. Our OFCs are manufactured in fully automated and controlled environments at our three state-of-art manufacturing facilities in Goa, Chennai (Tamil Nadu), and Hyderabad (Telangana).
Unarmoured cables are widely used in underground ducts. Cables are designed for the duct pulling or duct Blowing. Cables designs are customized on the basis of customer specifications, cable duct ratio and mechanical performance requirements to meet the desired application.
| Construction | Fiber count | Diameter (mm) | Switch Variants | Crush Resistance (N/10cm) | |
|---|---|---|---|---|---|
| Installation | Operational | ||||
| Unitube Unarm | 2-48F | 6.0-6.5 | 800 | 500 | 1000 |
| Multitube Arm | 4-432F | 9.0-18.0 | 1500-2500 | 1000-2000 | 1000 |
Loose fibers in jelly-filled tubes ranging from 2F-432F are offered in both unitube and multitube construction that makes the cable suitable for both blowing and manual pulling applications.
High fiber counts ranging from 96-1152F are offered in 6/8/12F ribbons that saves time and efforts by splicing all fibers in the ribbon in a single go, instead of individually splicing the fibers.
| Name | File |
|---|---|
| Duct Multitube With Ribbon Fibers | D-MT-RF.pdf |
| Duct Unitube | D-UT.pdf |
| Duct Unitube With Embedded FRP | D-UT-2FRP.pdf |
| Duct Unitube With Ribbon Fibers | D-UT-RF.pdf |
| Duct Multitube | D-MT.pdf |
These cables are designed for overhead pole to pole deployment. Cables are manufactured for pole distance ranging from 30 meters to 500 meters span. Installation is comparatively cost effective and faster as compared to underground deployment.
For overhead pole to pole deployment. Cables are manufactured for pole distance ranging from 30 mtrs to 500 mtrs span. Installation is comparatively cost effective and faster as compared to Underground deployment.
Product Brochure for DataFly
Microduct cables are low diameter cables that are used in micro ducts often in distribution and last mile networks. With emerging needs of maximum utilization of duct space for more and more data, HFCL’s Microduct cabling solution offers 3 variants of low diameter micro cables that can be blown inside micro ducts- standard, extra-thin and ultra-thin.
Product Brochure for DataFly
FTTH cable range are specifically designed for last mile connectivity solutions. These cables are available in both single mode and multimode constructions and are specifically designed to suit applications like data centers, pole dropping, premise distribution, riser and plenum. Cables for indoor application are manufactured with Low Smoke Zero Halogen (LSZH) polymer, which is a high-grade flame retardant
Product Brochure for DataFly
These cables are manufactured in loose micromodules that offer a perfect solution for midspan accessibility of fibers without cutting the cable.
| Fiber count | Diameter (mm) | Tensile Strength (N) | Crush Resistance (N/10cm) | |
|---|---|---|---|---|
| Installation | Operational | |||
| 12-288F | 6.5-13.5 | 1000-3200 | 700-1200 | 2500 |
Product Brochure for DataFly
